- Allowable Voltage
- 3.3 V ± 5%
- Application
- Client PCs, game consoles
- Average Power Consumption
- Read 8.1 W / Write 7.9 W
- Brand
- Samsung
- Cache Memory
- Samsung 2GB LPDDR4X SDRAM
- Capacity
- 2TB
- Controller
- Samsung in-house controller
- Device Sleep Mode
- Supported
- Dimensions (W x H x D)
- 80.15 x 22.15 x 2.38 mm (max)
- Encryption
- AES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (encrypted drive)
- Form Factor
- M.2 2280
- Garbage Collection
- Auto Garbage Collection Algorithm
- Heatsink
- No
- Installation Kit
- Not included
- Interface
- PCIe 5.0 x4, NVMe 2.0
- Management Software
- Samsung Magician
- Manufacturer Part Number
- MZ-VAP2T0BW
- Model
- 9100 PRO
- Operating Temperature
- 0 - 70 °C
- Product Type
- Internal solid state drive (SSD)
- Random Read
- Up to 1,850,000 IOPS
- Random Write
- Up to 2,600,000 IOPS
- Reliability (MTBF)
- 1.5 million hours
- S.M.A.R.T. Support
- Supported
- Sequential Read
- Up to 14,700 MB/s
- Sequential Write
- Up to 13,400 MB/s
- Shock
- 1,500 G & 0.5 ms (half sine)
- Storage Memory
- Samsung V-NAND TLC
- TRIM Support
- Supported
- Warranty
- 5-year limited warranty or 1,200TBW, whichever comes first
- Weight
- 9.0 g (max)
